A572S355JR Carbon Steel Coil
Classification :
A572/S355JR Carbon Steel Coil Description
A572 is a low-carbon, low-alloy high-strength steel coil produced employing the electric furnace steelmaking technology. So the main component is scrap iron. Owing to its reasonable composition design and strict process control, A572 steel coil is widely favored for high purity and excellent performance. Its molten steel pouring manufacturing method not only gives the steel coil good density and uniformity, but also ensures that the steel coil has superior mechanical properties after cooling. A572 carbon steel coil is widely used in construction, bridges, heavy machinery and other fields. At the same time, it performs well in welding, forming and corrosion resistance with its low carbon and low alloy characteristics.
Product Parameters
Product Name | A572/S355JR Carbon Steel Coil |
Production Process | Hot Rolling, Cold Rolling |
Material Standards | AISI, ASTM, ASME, DIN, BS, EN, ISO, JIS, GOST, SAE, etc. |
Width | 45mm-2200mm |
Length | Custom Size |
Thickness | Hot Rolling: 2.75mm-100mm |
Delivery Conditions | Rolling, Annealing, Quenching, Tempered or Standard |
Surface Process | Ordinary, Wire Drawing, Laminated Film |
Chemical Composition
A572 | C | Mn | P | S | Si |
Grade 42 | 0.21 | 1.35 | 0.03 | 0.03 | 0.15-0.4 |
Grade 50 | 0.23 | 1.35 | 0.03 | 0.03 | 0.15-0.4 |
Grade 60 | 0.26 | 1.35 | 0.03 | 0.03 | 0.40 |
Grade 65 | 0.23-0.26 | 1.35-1.65 | 0.03 | 0.03 | 0.40 |
Mechanical Properties
A572 | Yield Strength (Ksi) | Tensile Strength (Ksi) | Elongation % 8 inches |
Grade 42 | 42 | 60 | 20 |
Grade 50 | 50 | 65 | 18 |
Grade 60 | 60 | 75 | 16 |
Grade 65 | 65 | 80 | 15 |
Physical Performance
Physical Performance | Metric | Imperial |
Density | 7.80 g/cc | 0.282 lb/in³ |
Scope of Application
ASTM A572 carbon steel low-alloy steel is widely used as bridge panels, support plates, mechanical mounting plates, etc. for construction equipment, transmission towers, racks and other equipment.
Equivalent Material
EU | German Standard | Japanese Standard | French Standard | British Standard | Canada | Italy | Spain | National Standard | International | Portugal | India |
EN | DIN, WNr | JIS | AFNOR | BS | HG | UNI | UNE | GB | ISO | NP | IS |
S355JR | St52-3 | SM490A | E36-2 | 50B | 350W | Fe510B | AE355B | Q345B | E355C | FE510-B | IS961 |
APPLICATION FIELD
Bridge
Oil pipeline
Chemical industry
Steel structure
FAQ
How can we guarantee quality?
Always final Inspection before shipment;
Please feel free to leave us message if you have any question about us and our products.
How long is your delivery time?
Can we visit your factory?
About the product price?
Can you arrange the shipment?
Can you provide sample?
